DS-250 N 1500   With thermic and overload security switches. Except three-phase motors.
Water pump refrigeration of blade with flow control valve.
Diamond blade Ø10” (250mm) not included.
With a double set of flanges, one especially designed for miter cuts.
Motor assembly mounted on sliding bearings for maximum accuracy miter cuts.
Safety protector for segmented blades.
With lateral stop for repetitive cuts.
Retractable legs with "shield" function and wheels for easy transportation.
Removable water tank system.
2mW line laser.
Spirit level for easy field installation.
Machine supplied without cable.

Power Cutting height Foldable head Repetitive cuts Angular measurement INCH/MM. ruler Adjustable flow Laser Level Zero Dust 1 hour of continous work maximum, recommended by TNO 3 hours of continous work maximum, recommended by TNO
fons granate
REF.

 Performance level Power supply Revolutions per minute Cutting length Diagonal cutting length Cutting height Mitre Thickness cut Inside diameter Outside diameter Length Width Height (machine overall dimensions) Net weight without packaging Gross weight Units per box Units per pallet
fons granate
DS-250 N 150052940PREMIUM 230V-50 Hz. 2800 152 cm107,5x107,5 cm51 mm25 mm25,4 mm250 mm220x86x127 cm100 kg125 kg1 **1
fons gris
DS-250 N 150052941PREMIUM 230V-50 Hz. UK 2800 152 cm107,5x107,5 cm51 mm25 mm25,4 mm250 mm220x86x127 cm100 kg125 kg1 **1
fons gris
DS-250 N 150052942PREMIUM 220V-60 Hz. 3400 152 cm107,5x107,5 cm51 mm25 mm25,4 mm250 mm220x86x127 cm100 kg125 kg1 **1
fons gris
DS-250 N 150052943PREMIUM 110V-50 Hz. 2800 152 cm107,5x107,5 cm51 mm25 mm25,4 mm250 mm220x86x127 cm100 kg125 kg1 **1
fons gris
DS-250 N 150052944PREMIUM 120V-60 Hz.Inch. 3400 152 cm107,5x107,5 cm51 mm25 mm25,4 mm250 mm220x86x127 cm100 kg125 kg1 **1
fons gris
DS-250 N 150052945PREMIUM 380V-50 Hz. 3F 2800 152 cm107,5x107,5 cm51 mm25 mm25,4 mm250 mm220x86x127 cm100 kg125 kg1 **1
fons gris
DS-250 N 1500 USA52946PREMIUM 120V-60 Hz.Inch. 3400 152 cm107,5x107,5 cm51 mm25 mm25,4 mm250 mm220x86x127 cm100 kg125 kg1 **1
fons gris
fons gris

DS-250 N 1500 2
